Hobbywing Tunalyzer Hobbywing Tunalyzer

Product Name

Tunalyzer

Product Number

30504003

Specifications

Input Voltage Maximum test current Motor Type Size Weight Display Function

6-16.8V(2-4S Lipo) 18A Sensored&Sensorless Brushless Motor 122.8 x 64.6 x 39mm(with knob height) 144g LCD color touch screen 1) Measure motor Current / Kv value/Rpm, End-bell timing / Deviation, Rotor asymmetry, Hall signal deviation and motor temperature. 2) Set and upgrade the esc (which can support the OTA Bluetooth module)
